Omega 23221C

Description

The Omega 23221C Truck Axle Jack is designed to handle big jobs for big equipment.  With up to 22 tons of lifting capacity this axle jack has three handle angles to store the jack without taking up significant shop space, easily roll the jack to the vehicle, and at zero degrees it allows you to position the jack where you need it.

The heat treated extension screw and patented built in by-pass ensures reliability without damaging the jack when you’re just not exactly sure how much weight you’re lifting.

Features:

• A choice of three handle angles:
  – 90º for space saving storage
  – 45º for easy carrying movement
  – 0º for access to lifting point
• Heat-treated extension screw allows low pick-up height adjustment and maximum lift height
• U.S. Patented built-in by-pass device protects hydraulic system from over pumping damage
• Large steel rims with rubber wheels for easy positioning and smooth motion
• Sturdy one piece handle assembly is standard on all Omega Truck Jacks
• User friendly, self-returning spring minimizes operators effort, greatly reducing fatigue
• In-line air filter traps contaminates and protects air motor for longer life
• Chrome plated rams

Specifications:

• 22 Ton Capacity
• Minimum Height: 9 3/4″
• Maximum Height: 21 3/4″
• Lifting Range: 5 5/8″; Extension Screw 3 7/8″

Omega is a professional offshore line of lifting products and shop equipment.  Their products are designed with the features and rugged durability required by professionals. The factories use advanced technology to process machine, weld, fabricate, and paint the finished products.

Exceptional engineering with the added security of ANSI certification, means Omega products represent the best values available in the professional market. Products like this Omega 23221C truck jack, offer a one year manufacturer’s warranty.
