Omega 23227

Description

The Omega 23227 Truck Axle Jack is built tough.  It is designed to handle big jobs for big equipment.  With up to 100 lbs. of lifting capacity this axle jack has three handle angles to store the jack without taking up significant shop space, easily roll the jack to the vehicle, and at zero degrees it allows you to position the jack where you need it.

The heat treated extension screw and patented built in by-pass ensures reliability without damaging the jack when you’re just not exactly sure how much weight you’re lifting.

Features & Benefits:

• A choice of three handle angles:
  – 90º for space saving storage
  – 45º for easy carrying movement
  – 0º for access to lifting point
• Heat-treated extension screw allows low pick-up height adjustment and maximum lift height
• U.S. Patented built-in by-pass device protects hydraulic system from over pumping damage
• Large steel rims with rubber wheels for easy positioning and smooth motion
• Sturdy one piece handle assembly is standard on all Omega Truck Jacks
• User friendly, self-returning spring minimizes operators effort, greatly reducing fatigue
• In-line air filter traps contaminates and protects air motor for longer life
• Chrome plated rams
• High speed air turbo motor US patent number: 5,341,723 is equipped to raise the load to the desired height efficiently, effortlessly and safely
• Dual stage lifting operation
• Capacity 22/35 tons
