Tuxedo TC-950WPA | WB-953 Combo

Description

Tuxedo TC-950WPA Tire Changer and WB-953 Wheel Balancer Combo Package

The Tuxedo TC-950WPA and WB-953 Combo Package gives professional shops and home garages everything they need for complete wheel service. Together, these two machines handle tire changes and wheel balancing from one streamlined setup. Additionally, buying them as a combo saves money and gets your shop up and running faster.

The TC-950WPA is Tuxedo’s commercial-grade tire changer with a left-side pneumatic press arm. It handles tires up to 47″ in diameter and rim widths up to 15″. Furthermore, the press arm takes on low-profile and stiff sidewall tires that push standard machines to their limits.

The WB-953 pairs perfectly alongside the TC-950WPA. It balances wheels up to 39″ in diameter and supports rims up to 24″. Moreover, the LED touch-panel and self-calibration system set it apart in this price class. Multi-user operation also adds real value in any busy shop. This heavy-duty equipment is designed to deliver maximum performance in professional and home garage environments.

FEATURES

TC-950WPA Tire Changer

• Swing arm design handles tires up to 47″ in diameter and rim widths from 3″ to 15″
• Left-side pneumatic press arm simplifies changing low-profile and stiff sidewall tires
• Four pneumatic clamps with double-acting cylinders deliver powerful, reliable clamping force
• Side-mounted pneumatic bead breaker generates 5,512 lbs. of breaking force
• Bead seating inflation jets integrate directly into the clamping jaws for fast, safe inflation
• No-scratch design — the machine never contacts the rim, protecting alloy and custom wheels
• Large-diameter hex mount/demount shaft provides extra rigidity and long-term durability
• 26″ x 26″ square turntable accommodates a wide range of wheel sizes with ease
• Pressure regulator, oiler, and water separator come standard
• Foot-operated inflation with the tower serving as an auxiliary air tank
• Electric table rotation powered by a 1.5 HP, 110V motor

WB-953 Wheel Balancer

• Balances wheels up to 39″ in overall diameter with rim diameter support from 10″ to 24″
• LED touch-panel keypad with easy-to-read icons for fast, efficient operation
• Multi-mode balancing covers both car and motorcycle wheels
• Static, dynamic, and 3 ALU balancing modes with manual distance and diameter input
• Self-calibrating and self-diagnosing system improves accuracy and reduces downtime
• Integrated retractable measurement indicator speeds up data acquisition
• Multi-user operation lets two technicians work simultaneously with separate settings
• Integrated centering spring ensures quick, proper wheel mounting on the shaft
• Electronic braking system automatically slows the wheel after each balancing cycle
• Heavy-duty 36mm balancing shaft accommodates a wide range of wheel sizes and shapes
• Large 38″ hood shields technicians from debris; 23-pocket weight shelf keeps everything organized
• Includes: speed nut, 4 cone sizes (S/M/L/XL), weight hammer, wheel caliper, calibration weight, and bowl clamps

SPECIFICATIONS

TC-950WPA Tire Changer

• Max Wheel Diameter: 47″
• Wheel Width: 3″ – 15″
• Inside Rim Clamp Range: 15″ – 28″
• Outside Rim Clamp Range: 13″ – 24″
• Working Pressure: 8–10 bar (approx. 125 PSI)
• Bead Breaker Force: 5,512 lbs.
• Power Supply: 1.5 HP, 110V, single phase, 15 amp
• Turntable Size: 26″ x 26″
• Machine Weight: approx. 880 lbs.

WB-953 Wheel Balancer

• Max Overall Wheel Diameter: 39″
• Rim Diameter Range: 10″ – 24″
• Tire Width Range: 1.5″ – 20″
• Max Wheel Weight: 150 lbs.
• Balancing Shaft Diameter: 36mm
• Cycle Time: 10 seconds
• Hood Size: 38″
• Wheel Weight Shelf: 23 articulated pockets (over 1.5″ deep)

INSTALLATION:

Both machines ship via freight truck and require a forklift or loading dock for unloading. The TC-950WPA runs on a standard 110V, 15-amp, single-phase outlet. Additionally, it requires shop air at 8–10 bar (approximately 125 PSI). The WB-953 also connects to a standard 110V outlet. Furthermore, consult each machine’s installation manual for exact footprint dimensions and clearance requirements before setting up your wheel service area.

OPTIONS AVAILABLE

• Motorcycle tire adapter for the TC-950WPA
• Large-shaft motorcycle adapter kit for the WB-953 (19mm and larger shafts)
• Wheel weight kits compatible with the WB-953
• Rim protectors and bead blade accessories for the TC-950WPA
• Drip trays for both machines

Frequently Asked Questions

Q: What tire and rim sizes does the TC-950WPA handle?

A: The TC-950WPA handles tires up to 47″ in overall wheel diameter with rim widths from 3″ to 15″. Inside rim clamping covers 15″–28″, and outside clamping covers 13″–24″.

Q: Does the TC-950WPA work with low-profile and run-flat tires?

A: Yes. The left-side pneumatic press arm targets low-profile and stiff sidewall tires specifically. It applies controlled downward force during the mount and demount process, making otherwise difficult tires much easier to handle.

Q: What power and air supply does the TC-950WPA require?

A: The TC-950WPA runs on a standard 110V, single-phase, 15-amp outlet. It also requires a shop air compressor capable of delivering 8–10 bar, or approximately 125 PSI.

Q: Can the WB-953 balance motorcycle wheels?

A: Yes. The WB-953 includes a dedicated motorcycle balancing mode. Additionally, Tuxedo offers an optional large-shaft motorcycle adapter kit for heavier motorcycle wheels that require a 19mm or larger shaft.

Q: What warranty comes with this combo?

A: Tuxedo provides a one-year limited warranty on both machines. The warranty covers parts and workmanship defects under normal use. Tuxedo replaces any defective parts free of charge during that period.

Q: Does this combo require a loading dock for delivery?

A: Yes. Both machines ship via freight truck and require a forklift or loading dock for unloading. Contact Shop Tools Outlet before ordering for freight details and local warehouse pickup options.

WHY CHOOSE TUXEDO?

Tuxedo builds commercial-grade wheel service equipment that holds up in real shop conditions. Their machines serve tire shops, dealerships, fleet operations, and home garages that demand more than entry-level tools. Furthermore, Tuxedo backs every machine with dealer support and a one-year limited warranty, giving buyers confidence long after the sale.

The TC-950WPA and WB-953 sit at the core of Tuxedo’s wheel service lineup. Both deliver the features professionals rely on at a price point that makes sense for growing shops. Moreover, the combo format means two capable, matched machines that work together as a complete tire service solution.
